Especificaciones Técnicas
- Part Number: WL10186
- UPC Number: 765809321649
- Style: Spin-On Transmission Filter
- Service: Transmission
- Type:
- Media: Cellulose
- Height: 8.47 (215)*
- Outer Diameter Top: 3.83 (97)*
- Outer Diameter Bottom: Closed:
- Thread Size: M24x1.5
- Beta Ratio: 2/20/75=10/21/25
- Burst Pressure-PSI: 1893
- Max Flow Rate: 12-15 GPM
Diámetros
- Attached: 2.762 (70)* * 2.484 (63)* * 0.220 (6)*
Principales aplicaciones
- Principle Application: Case, John Deere, Doosan, Hitachi, New Holland. Terex, ZF transmissions, Other
| Nombre del fabricante | N° de pieza del fabricante |
|---|---|
| CASE CONSTRUCTION | 87519452 |
| CASE CONSTRUCTION | 84491498 |
| CATERPILLAR | 8036909 |
| DOOSAN | 47400021 |
| HITACHI | A0570013161 |
| HYUNDAI CONSTRUCTION | 31LM40090 |
| HYUNDAI CONSTRUCTION | ZGAQ00001 |
| HYUNDAI CONSTRUCTION | ZGAQ02400 |
| J.C.BAMFORD | 32/925197 |
| J.C.BAMFORD | 32/925905 |
| J.C.BAMFORD | 32/925905A |
| JOHN DEERE | AT222005 |
| JOHN DEERE | AT468647 |
| JOHN DEERE | AT336140 |
| KOMATSU | 42Y15H0V35 |
| LIEBHERR | 512600408 |
| LIEBHERR | 11836791 |
| NEW HOLLAND (CNH) | 84491498 |
| NEW HOLLAND (CNH) | 332202A1 |
| NEW HOLLAND (CNH) | 8603535 |
| NEW HOLLAND (CNH) | 8900126523 |
| TEREX | 1550 3244 |
| TEREX | 1527 3572 |
| TEREX | 4252 0612 |
| TEREX | 4504 9112 |
| VOLVO (TRUCKS/VCE/VME/PENTA) | 14507456 |
