R47D10GV2

Especificaciones Técnicas

• Part Number: R47D10GV2
• UPC Number: 765809701250
• Style: Cartridge Hydraulic Metal Canister Filter
• Service: Hydraulic
• Type: Full Flow/By-Pass
• Media: Microglass
• Height: 15.157 (385)*
• Outer Diameter: 2.894 (74)*
• Inside Diameter Top: Closed:
• Inside Diameter Bottom: 1.347 (34)*
• Thread Size:
• By-Pass Valve Setting-PSI: 87 PSI
• Beta Ratio: 200/9.9
• Nominal Micron Rating: 10
• Operating Temp. (min): -13
• Operating Temp. (max): 248
• Flow Direction: Outside-In
• Capacity: 81.45
• Filter Area: 832
